Product Details:
|
| Product Name: | Hydraulic Press Machine | Worktable Size: | Customized |
|---|---|---|---|
| Stroke: | Customized | Package: | Wooden Case/Pallet |
| Material: | Steel/ Aluminum/ Copper/ Iron | Max. Working Speed: | 20m/min |
| Power Supply: | 220V/380V/415V/440V | Warranty: | 1 Year |
| High Light: | Aluminum portable Hydraulic Press Machine,440V Hydraulic Press Machine,25MPA portable Hydraulic Press |
||
Hydraulic press equipment is designed for metal and non-metal sheet forming, stamping, punching and bending, widely used in various industries. This type of hydraulic press machine is equipped with modern control system, PLC/CNC, and power supply of 220V/380V/415V/440V. The size of worktable can be customized to meet different needs of customers.
The hydraulic pressure equipment is designed for high accuracy and long service life. It has the advantages of stable structure, low noise, low energy consumption and fast speed, which can maximize efficiency and reduce production cost. The hydraulic press machine is manufactured with high quality materials and advanced technology, and it can provide stable and reliable performance.
We provide comprehensive after-sale service, including online technical support, to ensure the best customer experience. All our products are carefully packed in wooden case or pallet to ensure they arrive in perfect condition. With our hydraulic press machine, you can achieve the desired forming results with high accuracy, efficiency and safety.
| 型号 | - | 25T | 40T | 63T | 100T | 160T | 250T | 400T | 500 T |
| force | kN | 250 | 400 | 630 | 1000 | 1600 | 2500 | 4000 | 5000 |
| Ejecting cylinder force | T | 200 | |||||||
| hydraulic fluid working pressure | MPa | 20,3 | 19,9 | 16,5 | 26,3 | 25 | 25 | 25 | 25 |
| stroke | mm | 350 | 400 | 500 | 500 | 500 | 600 | 1300 | 1300 |
| Fast approaching speed | mm/s | 48 | 33 | 39 | 36 | 24 | 23 | 15 | 15 |
| Return speed | mm/s | 115 | 94 | 84 | 98 | 65 | 55 | 80 | 80 |
| Throad depth | mm | 280 | 320 | 300 | 300 | 325 | 325 | 400 | 500 |
| Working table size | mm | 600x500 | 600x550 | 600x580 | 650x580 | 800x650 | 800x650 | 950x750 | 1600x1600 |
| Table height | mm | 730 | 730 | 730 | 730 | 730 | 800 | 800 | 800 |
| Hole diameter of table | mm | 100 | 100 | 120 | 120 | 140 | 200 | 200 | 200 |
| Motor power | kW | 5,5 | 5,5 | 7,5 | 11 | 11 | 22 | 30 | 35 |
| Overall dimension | mm | 1200 750 2100 |
1310 750 2330 |
1550 825 2350 |
1500 850 2400 |
1620 840 2820 |
2100 1280 3500 |
2300 1500 3800 |
2500 1700 4200 |
| Machine weight | kg | 2000 | 2500 | 3800 | 5500 | 6500 | 8000 | 16000 | 21000 |
| Parameter | Description |
|---|---|
| Product Name | Hydraulic Press Machine |
| Max. Working Speed | 20m/min |
| Pressure Range | 20.3MPA-25MPA |
| Max. Working Pressure | 25MPA |
| Max. Working Temperature | 120℃ |
| Worktable Size | Customized |
| Stroke | Customized |
| After-sale Service | Online Technical Support |
| Package | Wooden Case/Pallet |
| Warranty | 1 Year |
White Eagle's Hydraulic Press Machine is the perfect piece of equipment for any industrial or commercial application. With models ranging from 25T to 500T, this product is built to last and offers maximum efficiency and maximum working pressure of 25MPA and maximum working temperature of 120℃. The Worktable Size is customizable, and the control system can be PLC/CNC. It is certified by CE and ISO9001, and comes with a minimum order quantity of 1. The price is negotiable and the packing details are export package. Payment terms are available for T/T and Western Union. It is the perfect Hydraulic Press Equipment for any large-scale or small-scale industrial application. It is also the perfect choice for any Hydraulic Press Machine Manufacturer, as it is of the highest quality and comes with a competitive Hydraulic Press Machine Price.
White Eagle Hydraulic Press Equipment is your perfect choice for the Hydraulic Press Machine. Our Hydraulic Press Machine Price is negotiable and can meet your requirements on materials, such as Steel/ Aluminum/ Copper/ Iron. With CE, ISO9001 certification, it has a maximum working temperature of 120℃.
We provide online technical support, wooden cases/pallets for packaging, and accept payment by T/T and Western Union. The minimum order quantity is 1.
We provide comprehensive technical support and service for our Hydraulic Press Machine products. Our team of professionals is available to assist you with any technical questions, installation, repairs, and maintenance. All our technical support staff is experienced and knowledgeable in the use of Hydraulic Press Machine products. Our expert technicians can help you troubleshoot any problem and provide you with the most effective solutions.
We also offer training and education programs to help you understand and use the Hydraulic Press Machine products. Our training staff will provide you with the knowledge and skills to ensure that your Hydraulic Press Machine products are running optimally.
If you have any questions or concerns about your Hydraulic Press Machine products, please do not hesitate to contact us. Our friendly and knowledgeable customer service representatives will be happy to help you.
The Hydraulic Press Machine is securely packaged and shipped to ensure that it arrives safely and undamaged.
The package includes:
The Hydraulic Press Machine is shipped in a box with appropriate cushioning to protect it from any bumps or drops during transit.
The package is labeled with the customer's name, address, and contact information.
A1: The brand of the Hydraulic Press Machine is White Eagle.
A2: The model numbers of the Hydraulic Press Machine are 25T, 40T, 63T, 100T, 160T, 250T, 400T and 500T.
A3: The Hydraulic Press Machine is made in China Wuxi.
A4: The Hydraulic Press Machine has CE and ISO9001 certifications.
A5: The minimum order quantity of the Hydraulic Press Machine is 1.
